APC Symmetra LX Battery Module

SYBT5

APC Symmetra LX Battery Module

Extended run power protection for servers, networks, and telecommunications

Includes : Installation guide

  • Hot Pluggable Operation
    Add or remove servers without having to power off the switch.
  • Intelligent battery management
    Maximizes battery performance, life, and reliability through intelligent, precision charging.

Symmetra Battery Systems Features & Benefits

Product Distribution
Product Distribution

United Arab Emirates , Afghanistan , Antigua & Barbuda , Anguilla , Albania , Armenia , Netherlands Antilles , Angola , Argentina , Austria , Australia , Azerbaijan , Bosnia & Herzegovina , Barbados , Belgium , Burkina Faso , Bulgaria , Bahrain , Burundi , Benin , Bermuda , Bolivia , Brazil , Bahamas , Botswana , Belarus , Belize , Canada , Congo - Kinshasa , Switzerland , Côte d’Ivoire , Chile , Cameroon , China , Colombia , Costa Rica , Cyprus , Czechia , Germany , Djibouti , Denmark , Dominica , Dominican Republic , Algeria , Ecuador , Estonia , Egypt , Eritrea , Spain , Ethiopia , Fiji , France , Gabon , Grenada , Georgia , Ghana , Gambia , Guadeloupe , Greece , Guatemala , Guyana , Hong Kong SAR China , Honduras , Croatia , Haiti , Hungary , Indonesia , Ireland , Israel , India , Iraq , Iceland , Italy , Jamaica , Jordan , Kenya , Cambodia , St. Kitts & Nevis , South Korea , Kuwait , Cayman Islands , Kazakhstan , Lebanon , St. Lucia , Liberia , Lithuania , Luxembourg , Latvia , Morocco , North Macedonia , Mali , Myanmar (Burma) , Mongolia , Martinique , Mauritania , Malta , Malawi , Mexico , Malaysia , Mozambique , Namibia , Nigeria , Nicaragua , Netherlands , Norway , New Zealand , Oman , Panama , Peru , Philippines , Pakistan , Poland , Puerto Rico , Portugal , Paraguay , Romania , Rwanda , Saudi Arabia , Sweden , Singapore , Slovenia , Slovakia , Sierra Leone , Senegal , Somalia , Suriname , El Salvador , Turks & Caicos Islands , Togo , Thailand , Tajikistan , Turkmenistan , Tunisia , Turkey , Trinidad & Tobago , Taiwan , Tanzania , Ukraine , Uganda , United States , Uruguay , Uzbekistan , St. Vincent & Grenadines , Venezuela , U.S. Virgin Islands , Vietnam , Yemen , South Africa , Zambia , Zimbabwe

Print Technical Specification

Output

  • Battery Output Voltage
    120 V

Input

  • Number of Power Cords
    1

Batteries & Runtime

  • Battery type
    Lead-acid battery
  • Battery mounting
    Enclosed battery cartridge
  • Battery Placement
    Internal battery
  • Expected Battery Life (years)
    3 - 5
  • RBC Quantity
    1
  • Battery blocks per string
    10

Physical

  • Maximum Height
    5.51inches ( 140MM , 14.0CM )
  • Maximum Width
    8.27inches ( 210MM , 21.0CM )
  • Maximum Depth
    21.5inches ( 546MM , 54.6CM )
  • Net Weight
    64.15lbs. ( 29.1KG )
  • Shipping weight
    71.17lbs. ( 32.28KG )
  • Shipping Height
    15.16inches ( 385MM , 38.5CM )
  • Shipping Width
    29.53inches ( 750MM , 75.0CM )
  • Shipping Depth
    11.26inches ( 286MM , 28.6CM )

Environmental

  • Operating Temperature
    32 - 104 °F ( 0 - 40 °C )
  • Operating Relative Humidity
    0 - 95 %
  • Operating Elevation
    0 - 10000ft ( 0 - 3048meters )
  • Storage Temperature
    -15 - 45 °C
  • Storage Relative Humidity
    0 - 95 %
  • Storage Elevation
    0 - 15000ft ( 0 - 4572meters )

Conformance

  • Approvals
    CSA, UL 1778
  • Standard warranty
    2 years repair or replace

Sustainable Offer Status

  • RoHS
    Compliant
Manuals and Warranties
Title
Size
Updated On
PDF

Size

557KB

Updated On

2022-12-17

Agency Approvals
Title
Size
Updated On
PDF

Size

747KB

Updated On

2024-02-22

VDE for Symmetra (SYAF8KRMI,SYAF8KI,SYAF16KRMI,SYAF16KI,SYAF16KXR91,SYAF20KRMI,SYBT5)
